Nexen 912409 Air Engaged Positioning Tooth Clutch
- Write a review
$2,288.86
Air chamber volume0.763 in³Backlash0.28 °Bore detailsStraightBore size1.563 in, Machined Bore with KeywayBore styleMachined Bore with KeywayCE certifiedCEDrive inertia35.59 lbin²EnclosureOpenEngagement methodAirFinishMachined aluminum air chamberHose length8.25 inInlet size0.125-27 NPTMMaterials of constructionMachined Aluminum Air Chamber Black Oxide PilotMax allowable pressure (psi)120Max ambient temperature (°F)150Max operating pressure (psi)80Max Speed3000 RPMMax static clutch torque4900 inlbMin ambient temperature (°F)32Min engagement pressure (psi)20Min sprocket size40/36T, 50/30T, 60/26T, 80/20TMin static clutch torque1230 inlbMounting styleShaftNumber of engagement positions1, @ 360°Open or enclosed designOpenOutput bolt circle4.75 inOutput bolt hole size4 0.250-20 in, Holes @ 90°Output configurationPilotPilot size4.125 inPositioningPositioningProduct featuresAir Engaged, Spring Released, Pilot Mount, Single PositionRelease methodSpringRestrictionsConsult Nexen For Use In Cyclic Applications Or Engagement At Differential SpeedsRoHS compliantRoHSRPM3000Shaft inertia12.43 lbin²Unit height7 inUnit width7 in
Specifications
| Air chamber volume | 0.763 in³ |
| Backlash | 0.28 ° |
| Bore details | Straight |
| Bore size | 1.563 in, Machined Bore with Keyway |
| Bore style | Machined Bore with Keyway |
| CE certified | CE |
| Drive inertia | 35.59 lbin² |
| Enclosure | Open |
| Engagement method | Air |
| Finish | Machined aluminum air chamber |
| Hose length | 8.25 in |
| Inlet size | 0.125-27 NPTM |
| Materials of construction | Machined Aluminum Air Chamber Black Oxide Pilot |
| Max allowable pressure (psi) | 120 |
| Max ambient temperature (°F) | 150 |
| Max operating pressure (psi) | 80 |
| Max Speed | 3000 RPM |
| Max static clutch torque | 4900 inlb |
| Min ambient temperature (°F) | 32 |
| Min engagement pressure (psi) | 20 |
| Min sprocket size | 40/36T, 50/30T, 60/26T, 80/20T |
| Min static clutch torque | 1230 inlb |
| Mounting style | Shaft |
| Number of engagement positions | 1, @ 360° |
| Open or enclosed design | Open |
| Output bolt circle | 4.75 in |
| Output bolt hole size | 4 0.250-20 in, Holes @ 90° |
| Output configuration | Pilot |
| Pilot size | 4.125 in |
| Positioning | Positioning |
| Product features | Air Engaged, Spring Released, Pilot Mount, Single Position |
| Release method | Spring |
| Restrictions | Consult Nexen For Use In Cyclic Applications Or Engagement At Differential Speeds |
| RoHS compliant | RoHS |
| RPM | 3000 |
| Shaft inertia | 12.43 lbin² |
| Unit height | 7 in |
| Unit width | 7 in |
912409
