Nexen 966024 Spring Engaged Cylinder Mount Rod Lock
- Write a review
$2,778.56
Air chamber volume163.700 cmApproximate engagement response time130 msApproximate lifeMore Than 500, Manual ReleasesBacklash< 0.20 mmBadgeNexSafeCE certifiedCECylinder size125 mmEngagement methodSpringFinishBlack AnodizedIEC IP ratingIP67Inlet size0.250 BSPPLength197.5 mmLinear holding force8560 NManual release actuation torque100 Nm, 1/4 Turn Auto ResetManual release featureYesMaterials of constructionBlack AnodizedMax ambient temperature60 C, ContinuousMax intermittent ambient temperature100 C, IntermittentMax operating pressure (bar)8Min ambient temperature (C)0.5Min release pressure (bar)4.0Mounting styleCylinderNumber of slots for operating mode sensors1 Sensor Slot, None included, sold separately as accessoryOpen or enclosed designEnclosedProduct featuresSafety Rated, Spring Engaged, ISO Cylinder Mount, Sensor Slot, Manual ReleaseRelease methodAirRod diameter32 mmRod requirementsHRC60 Or Hard Chrome Plated Minimum Of 20 Microns, h8 Tolerance, Roughness 1.6 MicronsRoHS compliantRoHSSafety ratingNexSafe CertifiedStatic b10/b10d cycle life1000000/2000000Unit height10.75 inUnit width140 mm, X2
Specifications
| Air chamber volume | 163.700 cm |
| Approximate engagement response time | 130 ms |
| Approximate life | More Than 500, Manual Releases |
| Backlash | < 0.20 mm |
| Badge | NexSafe |
| CE certified | CE |
| Cylinder size | 125 mm |
| Engagement method | Spring |
| Finish | Black Anodized |
| IEC IP rating | IP67 |
| Inlet size | 0.250 BSPP |
| Length | 197.5 mm |
| Linear holding force | 8560 N |
| Manual release actuation torque | 100 Nm, 1/4 Turn Auto Reset |
| Manual release feature | Yes |
| Materials of construction | Black Anodized |
| Max ambient temperature | 60 C, Continuous |
| Max intermittent ambient temperature | 100 C, Intermittent |
| Max operating pressure (bar) | 8 |
| Min ambient temperature (C) | 0.5 |
| Min release pressure (bar) | 4.0 |
| Mounting style | Cylinder |
| Number of slots for operating mode sensors | 1 Sensor Slot, None included, sold separately as accessory |
| Open or enclosed design | Enclosed |
| Product features | Safety Rated, Spring Engaged, ISO Cylinder Mount, Sensor Slot, Manual Release |
| Release method | Air |
| Rod diameter | 32 mm |
| Rod requirements | HRC60 Or Hard Chrome Plated Minimum Of 20 Microns, h8 Tolerance, Roughness 1.6 Microns |
| RoHS compliant | RoHS |
| Safety rating | NexSafe Certified |
| Static b10/b10d cycle life | 1000000/2000000 |
| Unit height | 10.75 in |
| Unit width | 140 mm, X2 |
966024
