Nexen 927245 Multi-Caliper Tension Brake
- Write a review
$1,800.00
Actuation typeMultiple Actuators, 6 Diaphragm Actuators, 2 Small, 2 Medium, 2 LargeAnti rotation styleAnti-Rotation HolesApproximate brake facing life324 hphrBore detailsStraightBore size1.125 in, Machined Bore with KeywayBore styleMachined Bore with KeywayBrake facing edge color codeGreenBrake facing effective area5.0 in²Brake facing typeLow CoefficientBraking capabilityContinuous Slip, E-Stop, HoldingCE certifiedCEEnclosureOpenEngagement methodAirFinishMachined aluminumInlet size0.125 NPT, Or 5/32 in Plastic Tubing Fitting IncludedLength3.86 inMaterials of constructionMachined aluminumMax ambient temperature (°F)150Max brake continuous thermal dissipation0.72 hpMax dynamic torque with all calipers246 inlbMax dynamic torque with large pistons95 inlbMax dynamic torque with medium pistons67 inlbMax dynamic torque with small pistons43 inlbMax operating pressure (psi)85Max Speed3600 RPMMin ambient temperature (°F)32Min engagement pressure (psi)1Mounting styleShaftOpen or enclosed designOpenOuter Diameter6.62 inOutput shaft styleNoneProduct featuresAir Engaged, Shaft Mount, Multi-Caliper, Air Cooled, Medium DutyRelease methodSpringRoHS compliantRoHSRPM3600Shaft inertia16.7 lbin²Unit height9 inUnit width7 in
Specifications
| Actuation type | Multiple Actuators, 6 Diaphragm Actuators, 2 Small, 2 Medium, 2 Large |
| Anti rotation style | Anti-Rotation Holes |
| Approximate brake facing life | 324 hphr |
| Bore details | Straight |
| Bore size | 1.125 in, Machined Bore with Keyway |
| Bore style | Machined Bore with Keyway |
| Brake facing edge color code | Green |
| Brake facing effective area | 5.0 in² |
| Brake facing type | Low Coefficient |
| Braking capability | Continuous Slip, E-Stop, Holding |
| CE certified | CE |
| Enclosure | Open |
| Engagement method | Air |
| Finish | Machined aluminum |
| Inlet size | 0.125 NPT, Or 5/32 in Plastic Tubing Fitting Included |
| Length | 3.86 in |
| Materials of construction | Machined aluminum |
| Max ambient temperature (°F) | 150 |
| Max brake continuous thermal dissipation | 0.72 hp |
| Max dynamic torque with all calipers | 246 inlb |
| Max dynamic torque with large pistons | 95 inlb |
| Max dynamic torque with medium pistons | 67 inlb |
| Max dynamic torque with small pistons | 43 inlb |
| Max operating pressure (psi) | 85 |
| Max Speed | 3600 RPM |
| Min ambient temperature (°F) | 32 |
| Min engagement pressure (psi) | 1 |
| Mounting style | Shaft |
| Open or enclosed design | Open |
| Outer Diameter | 6.62 in |
| Output shaft style | None |
| Product features | Air Engaged, Shaft Mount, Multi-Caliper, Air Cooled, Medium Duty |
| Release method | Spring |
| RoHS compliant | RoHS |
| RPM | 3600 |
| Shaft inertia | 16.7 lbin² |
| Unit height | 9 in |
| Unit width | 7 in |
927245
