Nexen 835220 Spring Engaged Caliper Brake
- Write a review
$1,236.61
Approximate brake facing life616 hphrBacklash0.02 in, Linear Or Disc Working RadiusBrake air chamber volume when new0.624 in³Brake air chamber volume when worn out3.039 in³Brake facing edge color codePurpleBrake facing effective area17.6 in²Brake facing typeHigh CoefficientBrake peak thermal input rate44.00 hpBrake response factor0.072Brake torque2484 inlb, With A 24 in DiscBraking capabilityCyclic Dynamic, E-Stop, HoldingCE certifiedCEClamping force (psi)1130 lbf, @ 0Disc thickness0.500 inDisc working radiusWR=D/2-1.062 For 16 in Or Larger DiscsDynamic torque factor unburnished (psi)190 lbf, @ 0EnclosureOpenEngagement methodSpringFinishBlack oxideInlet size0.125 NPTMaterials of constructionBlack oxideMax allowable pressure (psi)120Max ambient temperature (°F)150Max static brake torque2484 inlb, With A 24 in DiscMin ambient temperature (°F)32Min release pressure (bar)5.99865 barMin release pressure (psi)87Open or enclosed designOpenProduct featuresSpring Engaged, Air Released, Foot Mount, Independent ActuatorsRelease methodAirRestrictionsConsult Nexen For Use In Cyclic ApplicationsRoHS compliantRoHSStatic torque factor unburnished (psi)224 lbf, @ 0
Specifications
| Approximate brake facing life | 616 hphr |
| Backlash | 0.02 in, Linear Or Disc Working Radius |
| Brake air chamber volume when new | 0.624 in³ |
| Brake air chamber volume when worn out | 3.039 in³ |
| Brake facing edge color code | Purple |
| Brake facing effective area | 17.6 in² |
| Brake facing type | High Coefficient |
| Brake peak thermal input rate | 44.00 hp |
| Brake response factor | 0.072 |
| Brake torque | 2484 inlb, With A 24 in Disc |
| Braking capability | Cyclic Dynamic, E-Stop, Holding |
| CE certified | CE |
| Clamping force (psi) | 1130 lbf, @ 0 |
| Disc thickness | 0.500 in |
| Disc working radius | WR=D/2-1.062 For 16 in Or Larger Discs |
| Dynamic torque factor unburnished (psi) | 190 lbf, @ 0 |
| Enclosure | Open |
| Engagement method | Spring |
| Finish | Black oxide |
| Inlet size | 0.125 NPT |
| Materials of construction | Black oxide |
| Max allowable pressure (psi) | 120 |
| Max ambient temperature (°F) | 150 |
| Max static brake torque | 2484 inlb, With A 24 in Disc |
| Min ambient temperature (°F) | 32 |
| Min release pressure (bar) | 5.99865 bar |
| Min release pressure (psi) | 87 |
| Open or enclosed design | Open |
| Product features | Spring Engaged, Air Released, Foot Mount, Independent Actuators |
| Release method | Air |
| Restrictions | Consult Nexen For Use In Cyclic Applications |
| RoHS compliant | RoHS |
| Static torque factor unburnished (psi) | 224 lbf, @ 0 |
835220
