| Air chamber volume | 9.180 cm |
| Approximate engagement response time | 35 ms |
| Backlash | < 0.20 mm |
| Badge | NexSafe |
| CE certified | CE |
| Cylinder size | 50 mm |
| Engagement method | Spring |
| Finish | Bare Aluminum |
| IEC IP rating | IP67 |
| Inlet size | 0.125 BSPP |
| Length | 105.3 mm |
| Linear holding force | 1400 N |
| Manual release feature | No |
| Materials of construction | Brushed Aluminum |
| Max ambient temperature | 60 C, Continuous |
| Max intermittent ambient temperature | 100 C, Intermittent |
| Max operating pressure (bar) | 8 |
| Min ambient temperature (C) | 0.5 |
| Min release pressure (bar) | 4.0 |
| Mounting style | Cylinder |
| Number of slots for operating mode sensors | 1 Sensor Slot, None included, sold separately as accessory |
| Open or enclosed design | Enclosed |
| Product features | Safety Rated, Spring Engaged, ISO Cylinder Mount, Sensor Slot |
| Release method | Air |
| Rod diameter | 20 mm |
| Rod requirements | HRC60 Or Hard Chrome Plated Minimum Of 20 Microns, h8 Tolerance, Roughness 1.6 Microns |
| RoHS compliant | RoHS |
| Safety rating | NexSafe Certified |
| Static b10/b10d cycle life | 1000000/2000000 |
| Unit height | 5.5 in |
| Unit width | 64 mm, X2 |
